Product Details:
Payment & Shipping Terms:
|
| Bearing Type: | Sealed Roller Bearing | Cutting Material: | TCI |
|---|---|---|---|
| Standard: | API-7-1, ISO 9001:2008 | Series: | FSA |
| IADC: | 517 | G: | Reinforced Gauge Protection |
| T: | Trimming Cutter | Shirttail: | Alloy Hard Facing Protection |
| High Light: | three cone bit,tricone rock roller bits |
||
9 7/8" FSA517GT , 250mm TCI Bit , Sealed Friction Bearing , Tricone Roller Bit , with Trimming Cutters
SIZE AVAILABLE
Form 3 7/8 inch to 26 inch
RECOMMENDED DRILLING PARAMETERS FOR APPLICATION
| Types & IADC Code | 417 |
437 447 |
517 527 |
537 547 |
617 627 |
637 | |
| WOB | KN/mm(Bit Dia.) | 0.4~0.9 | 0.4~0.9 | 0.35~1.0 | 0.5~1.0 | 0.6~1.1 | 0.7~1.2 |
| Lb/in. (Bit Dia.) | 2285~5142 | 2285~5142 | 2000~5714 | 2857~5714 | 3428~6285 | 4000~6857 | |
| Rotation Speed (Rpm) | 140~60 | 140~60 | 125~50 | 110~50 | 100~40 | 80~40 | |
The above chart represents commonly available sizes and types, we do produce other sizes and types of rock bits which do not appear on this list. Please contact us for more information.
The RPM applied to a bit will be a function of :
a. Type of bit
In general lower RPMs are used for insert bits than for milled tooth bits. This is to allow the inserts more time to penetrate the formation. The insert crushes a wedge of rock and then forms a crack which loosens the fragment of rock.
b. Type of formation
Harder formations are less easily penetrated and so require low RPM. A high RPM may cause damage to the bit or the drill string.
