| Brand Name: | FLRT |
| Model Number: | 6 FA517G |
| MOQ: | 20pcs |
| Supply Ability: | 200pcs per quarter |
6" TCI Tricone Bit , IADC 517 , TCI Bit , Sealed Journal Bearing
PRODUCT
Bit Size : 6" (152.4 mm)
IADC : 517
SERIES : FA
Cutting type: ( TCI ) Tungsten Carbide Insert
Connection : 3 1/2" API REG PIN
Nozzle : Three jet(side) nozzles
Bit weight: 14kgs
RECOMMENDED DRILLING PARAMETERS
| Types & IADC Code | 117 | 127 |
437 447 |
517 527 |
537 547 |
617 627 |
637
|
|
| WOB | KN/mm(Bit Dia.) | 0.35~0.8 | 0.35~0.9 | 0.35~0.9 | 0.35~1.0 | 0.45~0.95 | 0.45~1.1 | 0.5~1.1 |
| Lb/in. (Bit Dia.) | 2000~4271 | 2000~5142 | 2000~5142 | 2000~5714 | 2571~5714 | 2571~6285 | 2857~6285 | |
| Rotation Speed (Rpm) | 240~80 | 240~70 | 180~80 | 220~60 | 220~50 | 200~50 | 180~40 | |
FORMATIONS
Adapted to be used in soft to medium with low abrasive strength .
SIZE AVAILABLE
Form 7 7/8" to 17 1/2"
The above chart represents commonly available sizes and types, we do produce other sizes and types of rock bits which do not appear on this list. Please contact us for more information.
