|Bearing Type:||Sealed Journal Bearing With Gauge Protection||Cutting Material:||Tungsten Carbide|
|Standard:||API-7-1, ISO 9001:2008||Series:||FHO|
|Application 2:||Hole Opener Drilling|
Full HDD Hole Openers IADC 537,
Medium Hard HDD Rock Reamers,
Trenchless HDD Hole Openers
HDD Hole Openers , Reamer , IADC 537 , Single Cone Bit , Trenchless , Medium Hard Rock Reamer
1. Hole openers are designed for the enlargement of pilot holes and large hole applications. They are also used for road and river crossing application.
2. The hole openers are manufactured from AISI 4145H fully heat-treated alloy steel. All are available with carbide-milled teeth and insert cutters. Arms and cutters are hardfaced for protection in three different designs for varying conditions and rock formations. The design of the hole opener allows for field-changing the cutters. They has a wide range of hole opener types, including.
Combined by single TCI cone bit, IADC 537.
Seal and Lubrication
High performance HNBR O-ring for bearing seal and advanced grease for lubrication.
It is suitable for the large size well, HDD, trenchless and infrastructure applications.
It is suitable for the large size well, mining and infrastructure applications.
|28||711.2||117, 127, 517, 537, 617, 637|
|32||812.8||117, 127, 517, 537, 617, 637|
|38||914.4||117, 127, 517, 537, 617, 637|
