Product Details:
Payment & Shipping Terms:
|
| Bearing Type: | Sealed Journal Bearing | Cutting Material: | Steel Tooth / Milled Tooth |
|---|---|---|---|
| Standard: | API-7-1, ISO 9001:2008 | Series: | FSA |
| Name: | Oil Well Drill Bit | Application: | Oil Well Drilling |
| High Light: | mill tooth tricone bit,steel tooth rotary bits |
||
13 1/2" FSA127G , Steel Tooth Tricone Bit , Sealed Journal Bearing , Soft Formation , Shallow Well Drilling
SIZE AVAILABLE
From 5 7/8 inch to 26 inch
RECOMMENDED DRILLING PARAMETERS FOR APPLICATION
| Types & IADC Code |
116 117 |
126 127 |
136 137 |
216 217 |
246 247 |
326 327 |
|
| WOB | KN/mm(Bit Dia.) | 0.48~1.0 | 0.48~1.0 | 0.48~1.0 | 0.4~1.0 | 0.4~1.0 | 0.55~0.85 |
| Lb/in. (Bit Dia.) | 2742~5714 | 2742~5714 | 2742~5714 | 2285~5714 | 2285~5714 | 3140~4860 | |
| Rotation Speed (Rpm) | 160~80 | 150~70 | 130~60 | 100~60 | 80~50 | 60~45 | |
Product Description:
1) Short projection teeth with reduced crest length are used in this series of bit designs.
These bits are used to drill high-compressive strength, medium hard formations.
2) Durable hardfacing is applied to reduce tooth wear.
